Aluminum ringlock scaffolding
Aluminum ringlock scaffolding system is mainly composed of aluminum alloy and steel castings. It is characterized by lightweight, fast installation, good bearing capacity, and can be used with aluminum scaffolding planks. The Aluminum ringlock scaffolding system is suitable for complex environment, such as limited space, uneven ground and high height. Installation and demolition only 2-3 people, no special hoisting equipment, can be quickly installed and demolished.
1) Easy to handle
The aluminum ringlock scaffolding system requires no extra tools or loose fittings for its setup and dismantling. And aerial platform of 20m can be easily assembled by two persons within a short time. The whole process is as easy as toy bricks game.
2) Light in Weight
Manufactured with aluminum 6061-T6,Easily to be handled by a single worker
3) Versatility
Aluminum ringlock Scaffolding makes a great combination of simplicity and flexibility. It can be designed and assembled in many ways to suit different work environments.
4) High Recycle Rate
The used aluminum material is of greater recyclable value 40%, which is 35% higher than steel.
5) Tested Strength and Safety
The strength of components and joints is strictly tested. And the access deck can take 200kg/m2
Main components of Aluminium Ringlock Scaffolding: ringlock scaffolding Standard, ringlock scaffolding Ledger, ringlock scaffolding Diagonal Brace, Level Brace, Transom, Hop Up Bracket, Full Aluminum Deck (Plank), Aluminum Plywood Deck, Stair, Truss Transom, aluminum Beam, and so on.
Features
Quick erection and dismantling: aluminum ringlock scaffolding is all pre-measured and just a hammer is required when erection.
Safety: The reliable wedge connections prevent ledgers and diagonal braces from any kind of loosening. The rigid, right fit of all connections with concentric derivation of loads guarantees safety even at great heights.
Ringlock Scaffolding Standard Vertical
Aluminum Tube Dimension: O.D 48.4x4.2mm.
Alu Alloy Grade: 6061-T6, 6082-T6
Surface Finishing: Self-finishing, Powder Coated
Aluminum Tube Dimension: O.D 48.4x4.2mm.
Alu Alloy Grade: 6061-T6, 6082-T6
Ledger Connector: Casting aluminum
Common size for North America and Australia: 10', 8', 7', 6', 5', 4'2", 2'6".
Common size for Europe and South America: 3072mm, 2572mm, 2072mm, 1572mm, 732mm.
Surface Finishing: Self-finishing, Powder Coated
Ringlock Scaffolding Diagonal Brace
Aluminum Tube Dimension: O.D 48.4x4.2mm.
Alu Alloy Grade: 6061-T6, 6082-T6
Brace Connector: Casting aluminum
Common size for North America and Australia: 10', 8', 7', 6', 5', 4'2", 2'6".
Common size for Europe and South America: 3072mm, 2572mm, 2072mm, 1572mm, 732mm.
Surface Finishing: Self-finishing, Powder Coated
