You are here: Home » Products » Scaffolding Coupler » Double Coupler

Double Coupler



The Double Coupler is Right Angle Scaffold Clamp. It is used to connect two mutually perpendicular steel pipes at 90 degree. It is also called a 90 degree scaffold clamp.



In building construction, they are used to fix steel pipe scaffolds with an outer diameter of 48.3mm.



Double Coupler Manufacturer:

EK is a double coupler manufacturer in China, our couplers are made to BS1139 and EN74.



All types of double couplers:

  British Type Double Coupler

  British Type Pressed Double Coupler

  American Type Double Coupler

  German Type Double Coupler

  Australian Type Double Coupler

  Italian Type Malleable Lron Double Coupler

  Pressed Double Coupler

Related Products

British Type Pressed Double Coupler

Model: EK-P006
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 0.86kg
Model: EK-F014
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 1.00 kg

British Type Drop Forged Double Coupler

American Type Heavy Duty Double Coupler

Model: EK-F016
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 1.6kg
Model: EK-F019
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 1.2kg

German Type Double Coupler

Australian Type Double Coupler

Model: EK-F021
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 1.02 kg
Model: EK-F001
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 1.5 kg

Italian Type Malleable Lron Double Coupler

Pressed Double Coupler

Model: EK-P008
Tube Size: 48.3mm x 48.3mm
Material: Q235
Surface Treatment: Zinc-Plated
Weight: 0.55 kg

Double Coupler Scaffolding - EK

The double coupler is also called the right angle coupler, 90 degree scaffold clamp, right angle scaffold clamp, angle coupler. It connects the scaffold pipe at 90 degrees.



Your best supplier of scaffold ccouplers in China. EK is a manufacturer of scaffolding couplers for scaffolding companies worldwide. Importing scaffolding couplers directly from EK will bring you great cost savings.



EK's right angle couplers are widely used in construction projects, oil and gas transportation, dredging, piling, bridge construction and other works in various countries.





What is the difference between the drop forged double coupler and the pressed double coupler?



Drop forged coupler and pressed coupler are new scaffold couplers innovated and improved from raw materials and the production process after cast iron couplers.



Both of them are made of whole steel plate processing, but there are specific differences in production and product performance.



Drop forged coupler heats the raw material to a particular temperature and then use tools to forge forming. The pressed coupler is to use the raw material with the appropriate stamping die stamping forming.



The essential difference between pressed and drop forged is that pressed is cold deformation processing, drop forged is hot deformation processing.



That is to say, pressing is carried out at room temperature, forged is generally carried out in the hot state.
