Drop Forged Fixed Scaffold Girder Clamp Coupler

Share to:
Drop Forged Scaffold Fixed Girder Coupler 1) Material: Q235 2) Tube Size: 48.3mm 3) Surface Treatment: Zinc-Plated 4) Processing Way: Drop Forged 5) Color: White 6) Standard:N74-1:2005 Class B, AS1576.2, BS1139
Availability:
Quantity:
  • Drop Forged Fixed Girder Coupler
  • EK
  • 730890000
  • 48.3mm
  • Q235
  • Zinc-Plated
  • 1.47kg

Drop Forged Scaffolding Fixed Girder Clamp Coupler

Drop Forged Coupler can improve the efficiency of scaffolding removal, save working time. Due to the advanced technology, the anti-deformation and anti-tensile properties of the product is stronger. More suitable for scaffolding and firm in structure, not easy to slide down. Anti-rust treatment makes the drop forged double coupler last longer, it product after passivation, surface galvanized anti-rust treatment, Drop Forged Scaffolding Coupler corrosion resistance is better than the ordinary coupler.

All forged products use high-frequency electric furnace to heat different specifications of carbon structural steel to 950 ° C -1050 ° C austenite state, after 4000KN one-time forging can improve its organizational structure and mechanical properties, thereby improving the plasticity and mechanical properties of the product.

Product Specification

Commodity

Drop Forged Fixed Girder Coupler

Specification

48.3mm

Weight

1.47kg

Surface Treatment

Electro Galvanized

Material

Q235 Carbon Steel

Color

Blue-white, White, Colored, Etc

MOQ

1 Tons

Mark

Customize your Markings on Products

Processing Way

Drop Forging

Packing

Woven Bags with Wooden/Steel Pallets

Standard

EN74-1:2005 Class B, AS1576.2, BS1139

Certificate

SGS, EN12810, AS/NZS1576.3, ANSI10.8, CE, ISO9001, ISO14001, OHSAS18001

Payment

TT, L/C, D/P, Etc

Delivery Time

20-25 days after the order confirmed

Production Capability

2000 tons per month

Place of Origin

China

Main Market

South America, North America, Australia, European,   South Africa


Drop Forged Scaffolding Fixed Girder Clamp Coupler


Product Images

F011_02 fixed girder couplerFixed-Girder-Coupler (1)



Drop Forged Scaffolding Fixed Girder Clamp Coupler


Product Advantages

A. High quality materials, higher quality.

    Material--The product material is Q235 carbon steel which is higher than the standard as the raw material.
    Bolt--The bolt is 8.8 grade high-strength bolt, which ensures the quality.
    Quality assurance, more resistance to falls, improve the efficiency of scaffolding removal, saving time.

B. Advanced technology, better performance

    Products using advanced technology, avoid the production malpractice of old craft, causes the product the anti-deformation and the anti-stretching performance to be stronger, more fits the scaffolding, more firm, not easy to slide.

C. Anti-rust treatment, longer service life.

   After passivation and surface galvanized anti-rust treatment, it is corrosion resistance is better than the ordinary coupler, longer service life.

D. Standard production, more secure.

    According to the professional design and advanced technology, all products are manufactured in strict accordance with EN74 and BS1139 standards, quality guarantee, ensure construction safety and personnel safety.
