Galvanized or Painted Adjustable Scaffolding Telescopic Props Steel Support Shoring Props

Share to:

Adjustable Telescopic Props 1) Material: Q235 Carbon Steel 2) Tube Size: 57/48.3mm, 60/48.3mm 3) Thickness: 2mm, 3mm or per request 4) Adjustable Length: 0.5-0.8m, 1.0-1.8m, 1.6-3.5m or per request 5) Base Plate Size: 120x120mm, 140x140mm, 150x150mm 6) Base Plate Thickness: 3mm - 8mm or per request 7) Standard:BS1139, EN74 or request

Availability:

Quantity:



Inquire Add to Basket

Model:
Scaffolding Steel Prop
Brand:
EK
Code:
730890000
Tube Size:
57/48.3mm, 60.3/48.3mm
Material:
Q235
Surface Treatment:
Zinc-Plated
Weight:
per design

Product Description

Galvanized or Painted Adjustable Scaffolding Telescopic Props Steel Support Shoring Props

Product Description

Type	Light Duty Adjustable Telescopic Prop
Tube Size	57/48.3mm, 60.3/48.3mm or per design
Thickness	3mm or per design
Plate size	120mmx120mm, 140x140mm, 150x150mm, thickness 3-8mm or per design
Adjustable Length	1082-1782mm, 1842-3142mm, 1980-3350mm or per design
Main Material	Q235 or Q345
Type	Heavy duty, Light Duty
Color	Blue, yellow, red etc. or as requested
Surface treatment	Hot dip galvanized, pre-galvanized, Painted, galvanized, powder coated
Advantages	Competitive price, High-quality products, 24-hour after-sales service
Port	Nanjing/XINGANG
Application	Scaffolding and formwork
Currency	USD, RMB
Payment	L/C, T/T, 30% in advance
Package	Steel Pallet

Adjustable Height: 1082-1782mm

Outer Tube	Inner Tuber	Base Plate	Plug Pin	Nut	Weight (KG)
572995mm	48.321055mm	1201204mm	0.6mm	0.8mm	7.41
60.33995mm	48.331055mm	1501506mm	0.6mm	0.8mm	11.27
762.5995mm	63.53.21055mm	150x150x8mm	0.6mm	2.0mm	14.95
