| Availability: | |
|---|---|
| Quantity: | |
Steel Prop
EK
73084000
63.5mm*3.2mm
Q235
Hot-Dip Galvanized
20.9kg
Heavy duty steel props are temporary vertical support structures designed for applications such as concrete formwork, framing, and horizontal load-bearing. Our heavy duty acrow props offer the advantages of quick installation and precise height adjustment, suitable for supporting structures such as floor slabs, beams, platforms, and ceilings during pouring and curing. EK heavy duty scaffolding props are trusted by construction professionals worldwide for their strong support capacity and structural stability, suitable for construction sites of all sizes.
Heavy duty steel props are among the best-selling shoring posts on the market, available in various sizes and load-bearing ratings, reusable, and widely praised in the construction industry.
Advantages of Heavy Duty Steel Props:
Economical and Efficient: Heavy duty steel props are a more economical temporary support structure than permanent supports, offering a cost-saving option.
Easy to Operate: Shoring posts are very easy to install and operate. Simply stretch the inner tube to the appropriate height, and secure it by rotating the nut and locking pin, allowing the shoring posts to quickly reach the designated height.
Convenient Transportation: The foldable design minimizes the space occupied by shoring posts, facilitating handling and installation, reducing manpower and time.
Easy Maintenance: All shoring posts have an anti-corrosion and rust prevention treatment. Only regular checks for dirt and timely cleaning are required.
Heavy Duty Steel Props Specifications
Material: Q235/Q355 steel
Diameter: 63.5/76.1mm
Standards: EN1065, BS4360
Supporting Capacity: 20-30kN
Supporting Height: 1465mm-5500mm, customizable
Surface Treatment: Hot-dip galvanizing, electro-galvanizing, powder coating
Daily Production Capacity: 2000 pieces
Delivery Time: 10-30 days
Products Size
Heavy Duty Prop | |||
Adjustable Length | Out Tube | Inner Tube | Wall Thickness |
1400-2700mm | 60.3mm | 48.3mm | 1.6-5mm |
1600-2700mm | 60.3mm | 48.3mm | |
1620-2640mm | 60.3mm | 48.3mm | |
2000-3500mm | 60.3mm | 48.3mm | |
2200-3500mm | 60.3mm | 48.3mm | |
3000-5500mm | 60.3mm | 48.3mm | |
Surface Treatment | Painted, Power Coated, Electro Galvanized or Hot Dip Galvanized | ||
Why Choose EK Scaffolding's Heavy Duty Steel Props?
Certificate of Inspection Available
Factory Direct Sales, Competitive Prices
14 Years of Manufacturing Experience
Various Styles, Customization Available
Typing Service Available
Advanced Technology: Laser-cut inner tubes and top-of-the-line welding equipment
Heavy duty steel props are temporary vertical support structures designed for applications such as concrete formwork, framing, and horizontal load-bearing. Our heavy duty acrow props offer the advantages of quick installation and precise height adjustment, suitable for supporting structures such as floor slabs, beams, platforms, and ceilings during pouring and curing. EK heavy duty scaffolding props are trusted by construction professionals worldwide for their strong support capacity and structural stability, suitable for construction sites of all sizes.
Heavy duty steel props are among the best-selling shoring posts on the market, available in various sizes and load-bearing ratings, reusable, and widely praised in the construction industry.
Advantages of Heavy Duty Steel Props:
Economical and Efficient: Heavy duty steel props are a more economical temporary support structure than permanent supports, offering a cost-saving option.
Easy to Operate: Shoring posts are very easy to install and operate. Simply stretch the inner tube to the appropriate height, and secure it by rotating the nut and locking pin, allowing the shoring posts to quickly reach the designated height.
Convenient Transportation: The foldable design minimizes the space occupied by shoring posts, facilitating handling and installation, reducing manpower and time.
Easy Maintenance: All shoring posts have an anti-corrosion and rust prevention treatment. Only regular checks for dirt and timely cleaning are required.
Heavy Duty Steel Props Specifications
Material: Q235/Q355 steel
Diameter: 63.5/76.1mm
Standards: EN1065, BS4360
Supporting Capacity: 20-30kN
Supporting Height: 1465mm-5500mm, customizable
Surface Treatment: Hot-dip galvanizing, electro-galvanizing, powder coating
Daily Production Capacity: 2000 pieces
Delivery Time: 10-30 days
Products Size
Heavy Duty Prop | |||
Adjustable Length | Out Tube | Inner Tube | Wall Thickness |
1400-2700mm | 60.3mm | 48.3mm | 1.6-5mm |
1600-2700mm | 60.3mm | 48.3mm | |
1620-2640mm | 60.3mm | 48.3mm | |
2000-3500mm | 60.3mm | 48.3mm | |
2200-3500mm | 60.3mm | 48.3mm | |
3000-5500mm | 60.3mm | 48.3mm | |
Surface Treatment | Painted, Power Coated, Electro Galvanized or Hot Dip Galvanized | ||
Why Choose EK Scaffolding's Heavy Duty Steel Props?
Certificate of Inspection Available
Factory Direct Sales, Competitive Prices
14 Years of Manufacturing Experience
Various Styles, Customization Available
Typing Service Available
Advanced Technology: Laser-cut inner tubes and top-of-the-line welding equipment
