Drop Forged Single Coupler with Wedge
EK
730890000
48.3mm
Q235
Zinc-Plated
1.04kg
Drop Forged Single Coupler with Wedge Steel Scaffolding Fitting Clamp
Product Specification
Forged single coupler by Strongforge, connects two 48.3mm tubes at right angles. This fitting is designed for connecting board supports (transoms) or putlogs to ledgers in scaffolding and also used in lighting rigs, staging and guard rails. Single couplers can also be used to secure toe boards on a scaffold. This fitting is not designed to be load bearing – use a double if that is what you need.
All of our drop forged scaffold fittings are zinc plated for longer life, manufactured to BS1139 (Part 2) & EN74 and tested to ensure the highest level of quality control.
| Commodity | Drop Forged Single Coupler with Wedge |
Specification | 48.3*48.3mm |
Weight | 1.04kg |
Surface Treatment | Electro Galvanized |
Material | Q235 Carbon Steel |
| Function | with Anti-slide Rod welded wedge |
| Color | Blue-white, White, Colored, Etc |
MOQ | 1 Tons |
Mark | Customize your Markings on Products |
Processing Way | Drop Forging |
Packing | Woven Bags with Wooden/Steel Pallets |
Standard | EN74-1:2005 Class B, AS1576.2, BS1139 |
Certificate | SGS, EN12810, AS/NZS1576.3, ANSI10.8, CE, ISO9001, ISO14001, OHSAS18001 |
Payment | TT, L/C, D/P, Etc |
Delivery Time | 20-25 days after the order confirmed |
Production Capability | 2000 tons per month |
Place of Origin | China |
Main Market | South America, North America, Australia, European, South Africa |
