Galvanized Ringlock Vertical Scaffolding System Standard Round Ring
The rosette connection serves as the structural core of the ringlock scaffolding system. Each rosette features four large apertures and four small apertures, enabling components—such as ledgers, diagonal braces, beams, and triangular brackets—to connect simultaneously with the vertical standards from eight distinct directions. Thanks to its unique eight-hole geometric configuration, this connection point facilitates full 360-degree connectivity. Our ringlock rosette are manufactured from 10mm-thick Q355B steel and are seamlessly integrated with the vertical standards using a circumferential seam welding process executed by Golden Lion's automated welding machinery. This process ensures that the connection points possess high strength and semi-rigid characteristics, thereby fully meeting the load-bearing requirements stipulated by the EN 12810 standard for industrial and offshore scaffolding projects.
| Type | Typical Value | Notes |
| Large Holes | 4 | Used for connecting diagonal braces; allows for angular adjustment within a range of 45° to 60°. |
| Small Holes | 4 | Used for connecting ledgers; ensures a precise 90° right-angle connection. |
| Rosette Diameter | 123 mm | Standard industry specification. |
| Rosette Thickness | 10 mm | Manufactured from high-strength steel plate via stamping or precision casting. |
| Material | Q355B / S355JR | Matches the material of the vertical standards to ensure weld integrity. |
| Shear Capacity | 25.0 kN | Vertical shear load capacity per single node. |
| Torsional Rigidity | 0.8-1.0 kNm/rad | Determines the amplitude of scaffolding sway under wind loads. |
Descriptions:
Material: High Quality Q235 or 345 Strength Steel
Tube:48.3×3.25mm or other required
Surface Treatment: Galvanized, Hot Dip Galvanized, Painting, Powder coated, others
Packing: Steel Pallets with Plastic Membrane
Brand: RRICOM; RSF
OEM: Available
1.One set of Ringlock Scaffolding usually include 4 standards and 8 ledgers.
2.Ringlock Scaffolding is easy and quick to install and strip. which can save your time.
3.Ringlock Scaffolding provides high loading capacity while its structure is quite flexible.
4.All the Ringlock Scaffolding parts are dealt with CO2 arc welding, the surface is galvanized. As a result, it is more durable and has a longer working life.
5.There is small lock pin on Ringlock verticals to restrict the cups from moving out. so you don't worry to lost ancillaries.
