Standard Ringlock Scaffolding System

Standard Ringlock Scaffolding System

Product Advantage

A. High quality materials, higher quality.

    Material--The product material is Q235 or Q345 carbon steel which is higher than the standard as the raw material.
    Quality assurance, not easy to crush deformation.

B. Advanced technology, better performance

    Products using advanced technology, avoid the production malpractice of old craft, causes the product the anti-deformation and the anti-stretching performance to be stronger, more fits the scaffolding.

C. Anti-rust treatment, longer service life.

   After passivation and surface galvanized anti-rust treatment, it is corrosion resistance is better than the ordinary tubes, longer service life.

D. Standard production, more secure.

    According to the professional design and advanced technology, all products are manufactured in strict accordance with EN74 and BS1139 standards, quality guarantee, ensure construction safety and personnel safety.

Ringlock Standards

Ringlock scaffolding standards are vertical parts of ringlock system scaffold. They are fabricated by scaffolding pipe, rosettes, and scaffold spigots. While the rosette rings are welded on the scaffold tube at every 500 mm (250mm is available too).

Ringlock standards are the most important parts of the ringlock scaffolding system. It gives connectors for other ringlock scaffolding parts like rinlgock horizontals, ringlock braces, side brackets, lattice girders & beams, ringlock bridging, etc.

Ringlock O Ledger

Ringlock ledgers are horizontal parts of the ringlock system scaffolding. Thus you can call it ringlock horizontals.

Ringlock O ledgers are made by OD48.3mm standard scaffold tubes. At both ends of the ringlock O ledgers, there are two sets of ledger ends(heads) and wedge pins. The wedge pins are fixed on the ringlock ledgers by special rivets.

Ringlock U Ledger

Ringlock U ledgers are another type of ringlock system horizontals. Different from O ledgers,  U ledgers are made of ribbed U-shaped steel profiles.  Ringlock U ledgers are also called ringlock transoms too. Using U ledgers can avoid scaffold plank hooks conflicts happen in O ledger construction.
